Ultinon Drive 5100

4 inch LED light bar

LUMUD5101LX1

Ultinon Drive 5100 4 inch LED light bar

LUMUD5101LX1

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're heading. Spot hazards up to 240 metres away with lighting that performs in the most hostile environments and gives your vehicle a touch of style. See all benefits

Ultinon Drive 5100 4 inch LED light bar

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're heading. Spot hazards up to 240 metres away with lighting that performs in the most hostile environments and gives your vehicle a touch of style. See all benefits

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're heading. Spot hazards up to 240 metres away with lighting that performs in the most hostile environments and gives your vehicle a touch of style. See all benefits

Ultinon Drive 5100 4 inch LED light bar

Powerful brightness driving safety at the wheel

The Philips Ultinon Drive 5101L LED light bar has the power to keep you safer, wherever you're heading. Spot hazards up to 240 metres away with lighting that performs in the most hostile environments and gives your vehicle a touch of style. See all benefits

Similar products

See all LED light bars

Powerful brightness driving safety at the wheel

Bright, durable gear for overland journeys

  • Road-legal ECE R149-12.5
  • 1150 lm, 240 m beam length
  • Dual-colour position light
  • All terrain, all weather

Intense, far and wide illumination for superior visibility

The Philips Ultinon Drive 5101L LED light bar provides a brilliant light beam that illuminates the road ahead for up to 240 metres*. Its effective 1150 lumens are homogeneously distributed in an optimised indirect beam, generating intense illumination far and wide with reduced glare for everyday use. This enables drivers to react faster on dark, rural and dirt roads. Its cool, 6500 Kelvin light colour produces daylight conditions, improving contrast and helping drivers stay focused.

Choose your position-light colour

Never go unnoticed on side roads or in parking areas with the extra LED position lights of our Philips Ultinon Drive 5101L. Express your style and personality by choosing your light colour, either intense amber or cool white.

IP68 and IP69K-rated to master the elements

With its ingenious screwless design, the Philips Ultinon Drive 5101L LED light bar can withstand the wettest conditions. Its IP69K certification means it will perform, wherever your road leads and whatever the weather. And it will be more than a match for any power washer you use to clean your car afterwards.

Corrosion-free body, stainless-steel mounting brackets

With its anodised pre-treated and automotive-grade powder-top-coat body, the Philips Ultinon Drive 5101L LED light bar offers ultimate corrosion protection. Its mounting brackets are made of stainless steel, which is corrosion-free. It can withstand snow, ice and even salt. Built from durable, high-quality materials, your Philips auxiliary LED lights will provide years of reliable service.

Powerful road-legal LED lightbars

The Philips Ultinon Drive 5101L LED light bar meets ECE standards and is 100% road-legal for high-beam and position-light functions. For added safety, Philips LED light bars are tested to EMC R10 specification to ensure that they will function smoothly with your vehicle's electrical systems. The Philips Ultinon Drive 5101L LED light bar meets ECE standards and is 100% road-legal for high-beam and position-light functions. For added safety, Philips LED light bars are tested to EMC R10 specification to ensure that they will function smoothly with your vehicle's electrical systems.

Low-profile design for simpler fitting

The sleek, low-profile design makes installation easier, and flexible fitting options are possible with side-mounting brackets (included) and back-mounting brackets (UD1001M optional). Supplied with a pre-wired male/female 3-pin superseal DT connector, it is voltage-overload and reverse-polarity protected to make installation secure and easy.

Technical Specifications

  • Product description

    Boost mode activation
    No
    Break resistance
    Yes
    ECE R10
    Yes
    ECE R149
    Yes
    ECE reference number
    12.5
    Impact protection rating (IK)
    IK07
    Ingress protection rating (IP)
    IP68 and IP69K
    Installation angle
    360°
    Material
    Aluminium extruded
    Off-road boost
    No
    One-piece body design
    Yes
    Operating temperature
    -40° C to 80°C
    Range
    Ultinon Drive 51000
    Scratch-resistant lens
    Yes
    Technology
    LED
    Width
    150 mm/4  inch
    Boost function installation
    No
    Accessories (optional)
    LUMUD1001M, LUMUD1003W, LUMUD1004W
    corrosion-free brackets
    U-shaped mounting bracket
    ECE R148
    Yes
    Parking position light
    Yes, white or amber
    Plug type
    4-pin DT Connector with 0.5 m cable
  • Light characteristics

    Colour temperature
    6500 K  K
    Beam length 1 lux-m
    240
    Effective lumen output
    1150 lumens
    Raw lumen output
    4950 lumens
  • Electrical characteristics

    Voltage
    9-30 Volt DC
  • Ordering information

    Order entry
    UD5101LX1
    GOC
    01842750
  • Packaging Data

    EAN1
    8719018018427
    EAN3
    8719018018434
  • Packed product information

    MOQ (for professionals)
    8
    Box dimensions-L (mm)
    350
    Box dimensions-W (mm)
    90
    Box dimensions-H (mm)
    90
    Number of products in the box
    1 lamp
  • Outer pack information

    Length
    370  cm
    Width
    200  cm
    Height
    200  cm

Suggested products

Recently viewed products

  • Beam length measured on 1 lux.
