Business Monitor UltraWide LCD monitor with USB-C docking

40B1U5601H/01

Beyond well-equipped

This USB-C monitor is for data transfer, power delivery and watching videos. The integrated 5 MP webcam delivers sharp images, and the noise cancelling mic lets people hear you fine. Windows Hello Webcam for quick access and strong security.

See all benefits

Business Monitor UltraWide LCD monitor with USB-C docking

Similar products

See all Office monitors

Beyond well-equipped

with a pop-up webcam

  • 5000 series
  • 40 (39.53"/100.4 cm diag.)
  • 3440 x 1440 (WQHD)
RJ-45 to USB-C gives easy network connection with security

RJ-45 to USB-C gives easy network connection with security

Simplify all peripherals from monitor to PC using one-cable docking USB Type-C connector, including networking, high-resolution video output from PC to monitor, and surfing on the Internet without an additional network cable, even without a LAN port on your notebook. RJ45 connection through USB-C offers a fast and secure connection when needed. Getting the fastest data speeds allows you to transfer data from a HDD to your PC faster than ever. Additionally, USB-C with power delivery can even enable you to power and charge your notebook from the monitor, eliminating the need for extra power cables.

CrystalClear images with UltraWide QHD 3440 x 1440 pixels

CrystalClear images with UltraWide QHD 3440 x 1440 pixels

These Philips screens deliver Crystal Clear, UltraWide Quad HD 3440 x 1440 pixel images. Utilising high-performance panels with high-density pixel count and 178/178 wide viewing angles, these new displays will make your images and graphics come alive. The UltraWide 21:9 format enables more productivity with more room for side-by-side comparisons and more viewable spreadsheet columns. Whether you are a demanding professional requiring extremely detailed information for CAD-CAM solutions or a financial wizard working on huge spreadsheets, Philips displays deliver Crystal Clear images.

High Dynamic Range (HDR) for more lifelike colourful visuals

High Dynamic Range (HDR) for more lifelike colourful visuals

High Dynamic Range delivers a dramatically different visual experience. With astonishing brightness, incomparable contrast and captivating colour, images come to life with much greater brightness while also featuring much deeper, more nuanced darks. It renders a fuller palette of rich new colours never before seen on a display, giving you a visual experience that engages your senses and inspires emotions.

DisplayPort-out for connecting additional displays

DisplayPort-out for connecting additional displays

With DisplayPort-out you can connect multiple high-resolution displays with just one cable from your first display to the PC. The ability to daisy chain multiple displays enables you to maintain a clean desktop without the hassle of too many wires.

Built-in KVM switch to easily switch between sources

Built-in KVM switch to easily switch between sources

With the MultiClient Integrated KVM switch, you can control two separate PCs with one monitor-keyboard-mouse setup. A convenient button allows you to quickly switch between sources. Handy with setups that require dual PC computing power or sharing one large monitor to show two different PCs.

Webcam with noise-cancelling microphone for collaboration

Webcam with noise-cancelling microphone for collaboration

This Philips monitor comes with a built-in 5 MP webcam, noise-cancelling microphone and speakers, making it perfect for working from home and collaborating remotely. Equipped with advanced sensors for Windows Hello™ facial recognition, which conveniently logs you into your Windows devices in less than 2 seconds. The physical camera switch offers extra privacy when not in use. The noise-cancelling microphone and dual 5 watt integrated speakers deliver clear communication.

Accessory within reach

Accessory within reach

The unique design of the headphone hook on the side of the Philips monitor brings the tidiness and cable management of your working station to the next level. Its easy access lets you put aside your headphones easily, making sure that all of the accessories you need are within reach.

PowerSensor saves up to 80% energy costs

PowerSensor saves up to 80% energy costs

PowerSensor is a built-in 'people sensor' that transmits and receives harmless infrared signals to determine if the user is present and then automatically reduces monitor brightness when then user steps away from the desk, cutting energy costs by up to 80 percent and prolonging monitor life

MultiView enables simultaneous dual connection and view

MultiView enables simultaneous dual connection and view

With the ultra-high resolution Philips MultiView display, you can now experience a world of connectivity. MultiView enables active dual connect and view so that you can work with multiple devices like a PC and notebook simultaneously, for complex multitasking.

IPS LED wide view technology for image and colour accuracy

IPS LED wide view technology for image and colour accuracy

IPS displays use an advanced technology that gives you extra-wide viewing angles of 178/178 degrees, making it possible to view the display from almost any angle. Unlike standard TN panels, IPS displays give you remarkably crisp images with vivid colours, making them ideal not only for Photos, movies and web browsing, but also for professional applications that demand colour accuracy and consistent brightness at all times.

Technical Specifications

  • Picture/Display

    Panel Size
    40 inch
    Viewable Size
    39.53 inch/100.4 cm
    Aspect ratio
    21:9
    LCD panel type
    IPS technology
    Backlight type
    W-LED system
    Pixel pitch
    0.26925 x 0.26925 mm
    Brightness
    300  cd/m²
    Display colours
    16.7 M (8 bit)
    Colour gamut (typical)
    NTSC 102%*, sRGB 121%*
    Contrast ratio (typical)
    1200:1
    SmartContrast
    50,000,000:1
    Response time (typical)
    4 ms (Grey to Grey)*
    Viewing angle
    • 178º (H)/178º (V)
    • @ C/R > 10
    Picture enhancement
    SmartImage
    Maximum resolution
    HDMI: 3440 x 1440 @ 100 Hz, DP/USB-C: 3440 x 1440 @ 120 Hz
    Effective viewing area
    926.22 (H) x 387.72 (V)
    Scanning Frequency
    HDMI: 30 - 160 kHz (H) / 48 - 100 Hz (V); DP/USB-C: 30 - 190 kHz (H) / 48 - 120 Hz (V)
    sRGB
    Yes
    Delta E
    < 2
    Flicker-free
    Yes
    Pixel Density
    94 PPI
    LowBlue Mode
    Yes
    Display Screen Coating
    Anti-Glare, 3H, Haze 25%
    SmartUniformity
    93 ~ 105%
    EasyRead
    Yes
    HDR
    HDR 400 supported
  • Connectivity

    Signal Input
    HDMI 2.0 x 1, DisplayPort 1.4 x 1, USB-C x 2 (upstream, DP Alt mode, Data, PD up to 100 W)
    Sync Input
    Separate Sync
    Audio (In/Out)
    Audio out/Microphone in combo jack
    RJ45
    Ethernet LAN up to 1 G*, Wake on LAN
    Signal Output
    DisplayPort out x 1
    HDCP
    HDCP 1.4 (HDMI/DisplayPort/USB-C), HDCP 2.2 (HDMI/DisplayPort/USB-C)
    HBR3
    HBR3 (USB-C/DisplayPort)
    USB Hub
    USB 3.2 Gen 2 / 10 Gbps, USB-A downstream x 4 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15 W)
  • Power Delivery

    Max power delivery
    Up to 100 W* (5 V/3 A, 7 V/3 A, 9 V/3 A, 10 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/4.8 A)
    Version
    USB PD version 3.0
  • Convenience

    Built-in Speakers
    5 W x 2
    Plug and Play Compatibility
    • DDC/CI
    • Mac OS X
    • Windows 11/10/8.1/8/7
    • sRGB
    User convenience
    • Mic
    • SmartImage
    • Input
    • User
    • Menu
    • Power On/Off
    OSD Languages
    • Brazil Portuguese
    • Czech
    • Dutch
    • English
    • French
    • Finnish
    • German
    • Greek
    • Hungarian
    • Italian
    • Japanese
    • Korean
    • Portuguese
    • Polish
    • Russian
    • Simplified Chinese
    • Spanish
    • Swedish
    • Traditional Chinese
    • Turkish
    • Ukrainian
    Other convenience
    • Kensington lock
    • Earphone hook
    • VESA mount (100 x 100 mm)
    Control software
    SmartControl
    MultiView
    • PIP/PBP mode
    • 2 x devices
    Built-in webcam
    Pop-up 5.0 megapixel camera with a microphone and LED indicator (for Windows Hello)
    KVM
    Yes (USB-C/USB-C)
    Noise cancellation
    Yes
  • Stand

    Height adjustment
    150  mm
    Swivel
    -/+ 180  degree
    Tilt
    -5/30  degree
    Slant adjust
    -/+ 2 degrees
  • Power

    ECO mode
    31.4 W (typ.)
    Power supply
    • Built-in
    • 100–240 VAC, 50–60 Hz
    Off mode
    Zero watts with AC switch
    On mode
    40.2 W (typ.) (EnergyStar test method)
    Standby mode
    0.4 W (typ.)
    Power LED indicator
    • Operation - White
    • Standby mode - White (flashing)
    Energy Label Class
    G
  • Dimensions

    Packaging in mm (W x H x D)
    1070 x 507 x 226  mm
    Product without stand (mm)
    944 x 419 x 54  mm
    Product with stand (max height)
    944 x 628 x 280  mm
  • Weight

    Product with packaging (kg)
    17.83  kg
    Product with stand (kg)
    14.12  kg
    Product without stand (kg)
    9.90  kg
  • Operating conditions

    Altitude
    Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
    Temperature range (operation)
    0°C to 40  °C
    Relative humidity
    20%-80  %
    Temperature range (storage)
    -20°C to 60  °C
    MTBF (demonstrated)
    70,000 hrs (excluded backlight)
  • Sustainability

    Environmental and energy
    • Energy Star
    • PowerSensor
    • LightSensor
    • EPEAT*
    • RoHS
    Post-consumer recycled plastic
    85%
    Recyclable packaging material
    100  %
    Specific Substances
    • Mercury free
    • PVC/BFR free housing
  • Compliance and standards

    Regulatory Approvals
    • CB
    • CE Mark
    • EAEU RoHS
    • TUV Ergo
    • TUV/GS
    • ETL
    • TCO Certified
    • CEC
    • SEMKO
    • MEPS
    • PSB
    • PSE
    • KC
    • CEL
    • CCC
    • CECP
    • EMC
    • BSMI
    • VCCI
    • UKCA
    • EMF
    • FCC
    • ICES-003
  • Cabinet

    Finish
    Texture
    Foot
    Black
    Front bezel
    Black
    Rear cover
    Black
  • What's in the box?

    Cables
    HDMI cable, DisplayPort cable, USB-C to C cable, Power cable
    Monitor with stand
    Yes
    User Documentation
    Yes

Suggested products

Recently viewed products

  • "IPS" word mark / trademark and related patents on technologies belong to their respective owners.
  • Response time value equal to SmartResponse
  • NTSC Area based on CIE 1976
  • sRGB Area based on CIE1931
  • For Video transmission via USB-C, your Notebook/device must support USB-C DP Alt mode
  • Activities such as screen sharing and online streaming over the Internet can impact your network performance. Your hardware and network bandwidth will determine the overall audio and video quality.
  • For USB-C power and charging function, your Notebook/device must support USB-C standard Power Delivery specifications. Please check with your Notebook user manual or manufacturer for more details.
  • If your Ethernet connection seems slow, please enter the OSD menu and select USB 3.0 or a higher version that can support the LAN speed up to 1G.
  • The USB-C power delivery of this display is up to 100 W (96 W in typical). The maximum power delivery will depend on your device.
  • When calculating energy costs saving from PowerSensor, both USB and Power delivery are excluded.
  • EPEAT rating is valid only where Philips registers the product. Please visit https://www.epeat.net/ for registration status in your country.
  • The monitor may look different from feature images.
