LCD monitor with USB-C

246B1/01

LCD monitor with USB-C

246B1/01

Simplify your connections

The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits

LCD monitor with USB-C

Simplify your connections

The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits

Simplify your connections

The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits

LCD monitor with USB-C

Simplify your connections

The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits

Similar products

See all Office monitors

Simplify your connections

with USB-C docking

  • B Line
  • 24 (23.8"/60.5 cm diag.)
  • 2560 x 1440 (QHD)
USB-C enables laptop power charging directly from a monitor

USB-C enables laptop power charging directly from a monitor

This Philips display features a built-in USB type-C docking station with power delivery. With intelligent and flexible power management, you can power charge your compatible* laptop directly. Its slim, reversible USB-C connector allows for easy, one-cable docking. Simplify by connecting all your peripherals like keyboard, mouse and your RJ-45 Ethernet cable to the monitor's docking station. You can watch high-resolution video and transfer data at super-speed, while powering up and re-charging your notebook at the same time.

TUV Eye Comfort certified to reduce eye fatigue

TUV Eye Comfort certified to reduce eye fatigue

Philips displays meet TUV Rheinland Eye Comfort standard to prevent eye strain caused by prolonged computer use. With TUV Eye Comfort certification, Philips displays ensure flicker-free, low-blue mode, no disturbing reflections, a wide viewing angle, less reduction of image quality from different angles and ergonomic stand designs for an ideal viewing experience. Keep your eyes healthy and boost work productivity.

Less eye fatigue with Flicker-Free technology

Less eye fatigue with Flicker-Free technology

Due to the way brightness is controlled on LED-backlit screens, some users experience flicker on their screen which causes eye fatigue. Philips Flicker-Free technology applies a new solution to regulate brightness and reduce flicker for more comfortable viewing.

LowBlue Mode for easy-on-the-eyes productivity

LowBlue Mode for easy-on-the-eyes productivity

Studies have shown that just as ultra-violet rays can cause eye damage, shortwave-length blue light rays from LED displays can cause eye damage and affect vision over time. Developed for wellbeing, the Philips LowBlue Mode setting uses a smart software technology to reduce harmful shortwave blue light.

SmartErgoBase enables user-friendly ergonomic adjustments

SmartErgoBase enables user-friendly ergonomic adjustments

The SmartErgoBase is a monitor base that delivers ergonomic display comfort and provides cable management. The base can swivel, tilt and rotate to various angles to ensure maximum comfort. The height-adjustable stand guarantees the optimal viewing level, reducing the physical strains of a long workday, while cable management reduces cable clutter and keeps the workspace neat and professional.

PowerSensor saves up to 80% energy costs

PowerSensor saves up to 80% energy costs

PowerSensor is a built-in 'people sensor' that transmits and receives harmless infrared signals to determine if the user is present and then automatically reduces monitor brightness when then user steps away from the desk, cutting energy costs by up to 80 percent and prolonging monitor life

LightSensor for the perfect brightness with minimal power

LightSensor for the perfect brightness with minimal power

LightSensor uses a smart sensor to adjust the picture brightness depending on the light conditions in the room for the perfect picture with minimal power usage.

Built-in RJ-45 Ethernet gives data security

Built-in RJ-45 Ethernet gives data security

EasyRead mode for a paper-like reading experience

EasyRead mode for a paper-like reading experience

Designed to meet environmental standards

Designed for sustainability and reduced operating costs, this monitor meets environmental standards. Such as: ENERGY STAR, EPEAT, TCO Certified. For more information on certification, please visit: ENERGY STAR: https://www.energystar.gov/ EPEAT: https://www.epeat.net/ TCO Certified: https://tcocertified.com/

Technical Specifications

  • Picture/Display

    LCD panel type
    IPS technology
    Backlight type
    W-LED system
    Panel Size
    23.8 inch/60.5 cm
    Display Screen Coating
    Anti-Glare, 3H, Haze 25%
    Effective viewing area
    526.848 (H) x 296.352 (V)
    Aspect ratio
    16:9
    Maximum resolution
    2560 x 1440 @ 75 Hz*
    Pixel Density
    123 PPI
    Response time (typical)
    4 ms (Grey to Grey)*
    Brightness
    250
    Contrast ratio (typical)
    1000:1
    SmartContrast
    50,000,000:1
    Pixel pitch
    0.2058 x 0.2058 mm
    Viewing angle
    • 178º (H)/178º (V)
    • @ C/R > 10
    Picture enhancement
    SmartImage
    Display colours
    16.7 M
    Colour gamut (typical)
    NTSC 99%*, sRGB 116%*
    Scanning Frequency
    30–114 kHz (H)/48–75 Hz (V)
    sRGB
    Yes
    Flicker-free
    Yes
    EasyRead
    Yes
    LowBlue Mode
    Yes
  • Connectivity

    Signal Input
    DisplayPort 1.4 x 1, HDMI 1.4 x 2, USB-C 3.2 Gen 1 x 1 (upstream, power delivery up to 90 W)
    HDCP
    HDCP 2.2 (DP/HDMI/USB-C)
    HBR3
    HBR3 (USB-C)
    Signal Output
    DP out x 1
    USB:
    USB-C x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)
    Audio (In/Out)
    Audio out
    RJ45
    Ethernet LAN up to 1 G*, Wake on LAN
    Sync Input
    Separate Sync
  • USB

    USB-C
    Reversible plug connector
    Super speed
    Data and Video transfer
    DP
    Built-in Display Port Alt mode
    Power delivery
    USB PD version 3.0
    USB-C max. power delivery
    Up to 90 W (5 V/3 A, 7 V/3 A, 9 V/3 A, 10 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/4.5 A)
  • Convenience

    Built-in Speakers
    2 W x 2
    User convenience
    • SmartImage
    • Input
    • PowerSensor
    • Menu
    • Power On/Off
    Control software
    SmartControl
    OSD Languages
    • Brazil Portuguese
    • Czech
    • Dutch
    • English
    • Finnish
    • French
    • German
    • Greek
    • Hungarian
    • Italian
    • Japanese
    • Korean
    • Polish
    • Portuguese
    • Russian
    • Simplified Chinese
    • Spanish
    • Swedish
    • Traditional Chinese
    • Turkish
    • Ukrainian
    Other convenience
    • Kensington lock
    • VESA mount (100 x 100 mm)
    Plug and Play Compatibility
    • DDC/CI
    • Mac OS X
    • sRGB
    • Windows 10 / 8.1 / 8 / 7
  • Stand

    Height adjustment
    150
    Pivot
    -/+ 90 degree
    Swivel
    -/+ 180
    Tilt
    -5 ~ 35
  • Power

    ECO mode
    15.2 W (typ.)
    On mode
    17 W (typ.) (EnergyStar test method)
    Standby mode
    0.3 W (typ.)
    Off mode
    Zero watts with Zero switch
    Energy Label Class
    E
    Power LED indicator
    • Operation - White
    • Standby mode - White (flashing)
    Power supply
    • Built-in
    • 100–240 VAC, 50–60 Hz
  • Dimensions

    Product with stand (max height)
    540 x 500 x 205
    Product without stand (mm)
    540 x 323 x 51
    Packaging in mm (W x H x D)
    600 x 406 x 198
  • Weight

    Product with stand (kg)
    5.56
    Product without stand (kg)
    3.96
    Product with packaging (kg)
    8.23
  • Operating conditions

    Temperature range (operation)
    0°C to 40°C
    Temperature range (storage)
    -20°C to 60°C
    Relative humidity
    20%-80
    Altitude
    Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
    MTBF (demonstrated)
    70,000 hrs (excluded backlight)
  • Sustainability

    Environmental and energy
    • PowerSensor
    • LightSensor
    • EnergyStar 8.0
    • EPEAT*
    • TCO Certified Edge
    • RoHS
    Recyclable packaging material
    100
    Post-consumer recycled plastic
    85%
    Specific Substances
    • PVC/BFR free housing
    • Mercury free
  • Compliance and standards

    Regulatory Approvals
    • CB
    • TUV/GS
    • TUV Ergo
    • SEMKO
    • CU-EAC
    • EAEU RoHS
    • CE Mark
    • FCC Class B
    • ICES-003
    • TUV Eye Comfort certified
  • Cabinet

    Front bezel
    Black
    Rear cover
    Black
    Foot
    Black
    Finish
    Texture
  • What's in the box?

    Monitor with stand
    Yes
    Cables
    HDMI cable, DP cable, USB-C to C/A Y cable, Power cable
    User Documentation
    Yes

Suggested products

Recently viewed products

Awards

  • "IPS" word mark / trademark and related patents on technologies belong to their respective owners.
  • The maximum resolution works for either HDMI, DP or USB-C input.
  • Response time value equal to SmartResponse
  • NTSC Area based on CIE 1976
  • sRGB Area based on CIE1931
  • Activities such as screen sharing and online streaming over the Internet can impact your network performance. Your hardware and network bandwidth will determine the overall audio and video quality.
  • For USB-C power and charging function, your Notebook/device must support USB-C standard Power Delivery specifications. Please check with your Notebook user manual or manufacturer for more details.
  • For Video transmission via USB-C, your Notebook/device must support USB-C DP Alt mode
  • If your Ethernet connection seems slow, please enter the OSD menu and select USB 3.0 or a higher version that can support the LAN speed up to 1G.
  • EPEAT rating is valid only where Philips registers the product. Please visit https://www.epeat.net/ for registration status in your country.
  • The monitor may look different from feature images.
