LCD monitor with USB-C
246B1/00
- -{discount-value}for more information, download here (PDF 332.0KB)
LCD monitor with USB-C
246B1/00Simplify your connections
The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits
This product qualifies for VAT relief
If you're eligible for VAT relief on medical devices, you can claim it on this product. The VAT amount will be deducted from the price shown above. Look for full details in your shopping basket.
LCD monitor with USB-C
Simplify your connections
The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits
Simplify your connections
The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits
This product qualifies for VAT relief
If you're eligible for VAT relief on medical devices, you can claim it on this product. The VAT amount will be deducted from the price shown above. Look for full details in your shopping basket.
LCD monitor with USB-C
Simplify your connections
The Philips USB-C monitor replaces cable clutter. View QHD image, re-charge a laptop, all at the same time with a single USB-C cable. Features like Daisy chain for multi-display setup, Eye comfort with TUV certification to reduce eye fatigue. See all benefits
Similar products
See all Office monitors
USB-C enables laptop power charging directly from a monitor
This Philips display features a built-in USB type-C docking station with power delivery. With intelligent and flexible power management, you can power charge your compatible* laptop directly. Its slim, reversible USB-C connector allows for easy, one-cable docking. Simplify by connecting all your peripherals like keyboard, mouse and your RJ-45 Ethernet cable to the monitor's docking station. You can watch high-resolution video and transfer data at super-speed, while powering up and re-charging your notebook at the same time.
TUV Eye Comfort certified to reduce eye fatigue
Philips displays meet TUV Rheinland Eye Comfort standard to prevent eye strain caused by prolonged computer use. With TUV Eye Comfort certification, Philips displays ensure flicker-free, low-blue mode, no disturbing reflections, a wide viewing angle, less reduction of image quality from different angles and ergonomic stand designs for an ideal viewing experience. Keep your eyes healthy and boost work productivity.
Less eye fatigue with Flicker-Free technology
Due to the way brightness is controlled on LED-backlit screens, some users experience flicker on their screen which causes eye fatigue. Philips Flicker-Free technology applies a new solution to regulate brightness and reduce flicker for more comfortable viewing.
LowBlue Mode for easy-on-the-eyes productivity
Studies have shown that just as ultra-violet rays can cause eye damage, shortwave-length blue light rays from LED displays can cause eye damage and affect vision over time. Developed for wellbeing, the Philips LowBlue Mode setting uses a smart software technology to reduce harmful shortwave blue light.
SmartErgoBase enables user-friendly ergonomic adjustments
The SmartErgoBase is a monitor base that delivers ergonomic display comfort and provides cable management. The base can swivel, tilt and rotate to various angles to ensure maximum comfort. The height-adjustable stand guarantees the optimal viewing level, reducing the physical strains of a long workday, while cable management reduces cable clutter and keeps the workspace neat and professional.
PowerSensor saves up to 80% energy costs
PowerSensor is a built-in 'people sensor' that transmits and receives harmless infrared signals to determine if the user is present and then automatically reduces monitor brightness when then user steps away from the desk, cutting energy costs by up to 80 percent and prolonging monitor life
LightSensor for the perfect brightness with minimal power
LightSensor uses a smart sensor to adjust the picture brightness depending on the light conditions in the room for the perfect picture with minimal power usage.
EasyRead mode for a paper-like reading experience
Built-in RJ-45 Ethernet gives data security
Designed to meet environmental standards
Designed for sustainability and reduced operating costs, this monitor meets environmental standards. Such as: ENERGY STAR, EPEAT, TCO Certified. For more information on certification, please visit: ENERGY STAR: https://www.energystar.gov/ EPEAT: https://www.epeat.net/ TCO Certified: https://tcocertified.com/
Technical Specifications
-
Connectivity
- Signal Input
- DisplayPort 1.4 x 1, HDMI 1.4 x 2, USB-C 3.2 Gen 1 x 1 (upstream, power delivery up to 90 W)
- Sync Input
- Separate Sync
- Audio (In/Out)
- Audio out
- RJ45
- Ethernet LAN up to 1 G*, Wake on LAN
- Signal Output
- DP out x 1
- USB:
- USB-C x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)
- HDCP
- HDCP 2.2 (DP/HDMI/USB-C)
- HBR3
- HBR3 (USB-C)
-
Picture/Display
- Panel Size
- 23.8 inch/60.5 cm
- Aspect ratio
- 16:9
- LCD panel type
- IPS technology
- Backlight type
- W-LED system
- Pixel pitch
- 0.2058 x 0.2058 mm
- Brightness
- 250 cd/m²
- Display colours
- 16.7 M
- Colour gamut (typical)
- NTSC 99%*, sRGB 116%*
- Contrast ratio (typical)
- 1000:1
- SmartContrast
- 50,000,000:1
- Response time (typical)
- 4 ms (Grey to Grey)*
- Viewing angle
-
- 178º (H)/178º (V)
- @ C/R > 10
-
- Picture enhancement
- SmartImage
- Maximum resolution
- 2560 x 1440 @ 75 Hz*
- Effective viewing area
- 526.848 (H) x 296.352 (V)
- Scanning Frequency
- 30–114 kHz (H)/48–75 Hz (V)
- sRGB
- Yes
- Flicker-free
- Yes
- Pixel Density
- 123 PPI
- LowBlue Mode
- Yes
- Display Screen Coating
- Anti-Glare, 3H, Haze 25%
- EasyRead
- Yes
-
USB
- Power delivery
- USB PD version 3.0
- Super speed
- Data and Video transfer
- DP
- Built-in Display Port Alt mode
- USB-C max. power delivery
- Up to 90 W (5 V/3 A, 7 V/3 A, 9 V/3 A, 10 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/4.5 A)
- USB-C
- Reversible plug connector
-
Convenience
- Built-in Speakers
- 2 W x 2
- Plug and Play Compatibility
-
- DDC/CI
- Mac OS X
- sRGB
- Windows 10 / 8.1 / 8 / 7
-
- User convenience
-
- SmartImage
- Input
- PowerSensor
- Menu
- Power On/Off
-
- OSD Languages
-
- Brazil Portuguese
- Czech
- Dutch
- English
- Finnish
- French
- German
- Greek
- Hungarian
- Italian
- Japanese
- Korean
- Polish
- Portuguese
- Russian
- Simplified Chinese
- Spanish
- Swedish
- Traditional Chinese
- Turkish
- Ukrainian
-
- Other convenience
-
- Kensington lock
- VESA mount (100 x 100 mm)
-
- Control software
- SmartControl
-
Stand
- Height adjustment
- 150 mm
- Pivot
- -/+ 90 degree
- Swivel
- -/+ 180 degree
- Tilt
- -5 ~ 35 degree
-
Power
- ECO mode
- 15.2 W (typ.)
- Power supply
-
- Built-in
- 100–240 VAC, 50–60 Hz
-
- Off mode
- Zero watts with Zero switch
- On mode
- 17 W (typ.) (EnergyStar test method)
- Standby mode
- 0.3 W (typ.)
- Power LED indicator
-
- Operation - White
- Standby mode - White (flashing)
-
- Energy Label Class
- E
-
Dimensions
- Packaging in mm (W x H x D)
- 600 x 406 x 198 mm
- Product without stand (mm)
- 540 x 323 x 51 mm
- Product with stand (max height)
- 540 x 500 x 205 mm
-
Weight
- Product with packaging (kg)
- 8.23 kg
- Product with stand (kg)
- 5.56 kg
- Product without stand (kg)
- 3.96 kg
-
Operating conditions
- Altitude
- Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
- Temperature range (operation)
- 0°C to 40°C °C
- Relative humidity
- 20%-80 %
- Temperature range (storage)
- -20°C to 60°C °C
- MTBF (demonstrated)
- 70,000 hrs (excluded backlight)
-
Sustainability
- Environmental and energy
-
- PowerSensor
- LightSensor
- EnergyStar 8.0
- EPEAT*
- TCO Certified Edge
- RoHS
-
- Post-consumer recycled plastic
- 85%
- Recyclable packaging material
- 100 %
- Specific Substances
-
- PVC/BFR free housing
- Mercury free
-
-
Compliance and standards
- Regulatory Approvals
-
- CB
- TUV/GS
- TUV Ergo
- SEMKO
- CU-EAC
- EAEU RoHS
- CE Mark
- FCC Class B
- ICES-003
- TUV Eye Comfort certified
-
-
Cabinet
- Finish
- Texture
- Foot
- Black
- Front bezel
- Black
- Rear cover
- Black
-
What's in the box?
- Cables
- HDMI cable, DP cable, USB-C to C/A Y cable, Power cable
- Monitor with stand
- Yes
- User Documentation
- Yes
Suggested products
Recently viewed products
Awards
- "IPS" word mark / trademark and related patents on technologies belong to their respective owners.
- The maximum resolution works for either USB-C, DP or HDMI input.
- Response time value equal to SmartResponse
- NTSC Area based on CIE 1976
- sRGB Area based on CIE1931
- Activities such as screen sharing and online streaming over the Internet can impact your network performance. Your hardware and network bandwidth will determine the overall audio and video quality.
- For USB-C power and charging function, your Notebook/device must support USB-C standard Power Delivery specifications. Please check with your Notebook user manual or manufacturer for more details.
- For Video transmission via USB-C, your Notebook/device must support USB-C DP Alt mode
- If your Ethernet connection seems slow, please enter the OSD menu and select USB 3.0 or a higher version that can support the LAN speed up to 1G.
- EPEAT rating is valid only where Philips registers the product. Please visit https://www.epeat.net/ for registration status in your country.
- The monitor may look different from feature images.
