HeartStart Data Messenger

HeartStart defibrillator software
Download, store & send Philips AED data to where it’s needed most.

Features
Versatile defibrillator case processing
Download your patient case data from the AED or monitor and forward to your medical director, colleague, or patient's physician for analysis, erase it from the defibrillator, and synchronize case times and defibrillator clock with your PC.
Versatile defibrillator case processing
Simplify your workflow
HeartStart Data Messenger can process cases under your control in “manual mode” or simplify your responders’ job by processing cases automatically in the background, according to pre‐configured preferences – no need to interact with software.
Manual and automatic modes
Efficient batch processing
HeartStart MRx monitor/defibrillator users can automatically download multiple patient summaries at once via LAN and forward them all in one batch to either an Event Review Pro database or electronic patient care reporting system (ePCR).
Efficient batch processing


Specifications
  • Supported Defibrillators
    AEDs
    Philips and Laerdal HeartStart FR3, FR2+, FRx, HS1
    ALS Monitor/defibrillators
    Philips HeartStart MRx, XL, XLT. Laerdal HeartStart 4000
  • PC Hardware
    Processor speed
    1 GHZ or higher
    Display
    1280 x 768 or higher
    Memory
    1 GB or larger
    Disk storage space
    40 GB or larger
  • Software Platform
    Operating system
    Microsoft Windows: XP Professional SP 3 or later (32-bit) XP Tablet Edition (32-bit) Windows 7 (32-bit and 64-bit)
    Browser
    Microsoft Internet Explorer 7.0 or later
    Email application
    Send patient case data using email.MAPI‐compliant email client. Email client included: Windows XP Pro, Windows XP Tablet, Windows 2003 Server, Windows Vista, and Windows 7 installations.
  • Connectivity
    Internet or Intranet
    To download Data Messenger and activate it. To forward patient data to Event Review Pro Inbox or HeartStartTelemedicine
    Ethernet
    To forward HeartStart MRx data through batch LAN data transfers
    Bluetooth®
    MRx patient data using Bluetooth wireless transfer. Bluetooth adapter supporting Microsoft or Widcomm stack. Suggested adapter is IOGEAR Bluetooth 2.1 USB Micro Adapter (model GBU421).
    FTP server
    To support HeartStart MRx batch LAN data transfers
    Infrared (IRdA)
    To read patient cases from a HeartStart HS1 or FRx defibrillator.An infrared transceiver or adapter . Philips offers an infrared adapter, product number ACT‐IR.
    Card reader
    Secure Digital (SD) for FR3. Compact Flash for HeartStart MRx, FR2, XL, XLT, and 4000. Philips offers a compatible card reader, product number M3524A.


Documentation

Product Brochure Philips HeartStart AED software
PDF|186.53 KB
Product Brochure Philips HeartStart HeartStart defibrillator software Data Messenger
PDF|816.67 KB
Product Brochure Philips HeartStart AED software
PDF|619.24 KB

Related products

  • HeartStart Clinical Software
    HeartStart Event Review Pro offers a wide range of reports types, both at the case and institution level to add to a patient’s medical record, submit to national registries, and help refine training curriculum/code response.
  • HeartStart HeartStart AED software
    Configure your HeartStart AED from a computer, reflecting your medical director’s preferences.
Disclaimer
HeartStart FR3 and MRx defibrillators only
