This performance oriented ceiling mounted digital X-ray system with a fixed or wireless detector, motorized auto-tracking, a fully digital workflow, and UNIQUE image processing, delivers diagnostic quality images for fast, efficient exams.
This performance oriented ceiling mounted digital X-ray system with a fixed or wireless detector, motorized auto-tracking, a fully digital workflow, and UNIQUE image processing, delivers diagnostic quality images for fast, efficient exams.
Generator | 50 kW
|
65 kW
|
High-voltage generator | The converter generator generates high voltage equivalent to DC voltage
|
|
Mains voltage | 380V/400 V / 480 V (±10%); 50 Hz or 60 Hz, 3-phase
|
|
Max. mains resistance at 400 V | 0.3 Ohm
|
0.2 Ohm
|
Max. mains current at 400 V | 112A
|
134A
|
Nominal power (IEC) | 50 kW
|
65 kW
|
Max. tube voltage | 150 kV
|
150 kV
|
Max. tube current (at 80 kV) | 630 mA
|
800 mA
|
mAs product | 0.4 mAs to 850 mAs
|
0.4 mAs to 850 mAs
|
Exposure times | 1ms to 4s
|
1ms to 4s
|
Type | Manual, with light field indicator
|
Timer switch | 30 s (should be configurable)
|
Angle of aperture and rotation | ±45°
|
Two focal spots | RO1750 - 0.6 and 1.2
|
SRO 33100 - 0.6 and 1.2
|
Maximum power with focal spot 0.6 | RO1750 - 21 kW
|
3SRO 33100 - 3 kW
|
Maximum power with focal spot 1.2 | RO1750 - 60 kW
|
SRO 33100 - 100 kW
|
Anode angle | RO1750 - 13°
|
SRO 33100 - 13°
|
Maximum tube voltage | RO1750 - 150 kV
|
SRO 33100 - 150 kV
|
Anode heat storage capacity | RO1750 - 220 kJ (300 kHU)
|
SRO 33100 - 220 kJ (300 kHU)
|
Assembly heat capacity | RO1750 - 1500 kJ (2202.4 kHU)
|
SRO 33100 - 1500 kJ (2202.4 kHU)
|
Continuous anode input power | RO1750 - 250 W
|
SRO 33100 - 200 W
|
Minimum anode speed | RO1750 - 3000-3600 revolutions/minute
|
SRO 33100 - 9000-10800 revolutions/minute
|
Detector size | 43 cm x 43 cm (17"x 17")
|
Weight | 2.1 kg
|
Active area | 42.5 cm x 42.5 cm (16.7" x 16.7")
|
Detector pixels | 8.3 Megapixel
|
Pixel size | 148 μm
|
Image matrix size | 2,869 pixel x 2,874 pixel
|
Type | Digital GOS (Gadox) flat detector
|
Image resolution | up to 3.4 Lp/mm
|
Type | Digital wireless flat detector
|
Scintillator | Gadox
|
Image matrix size | 2476 x 3072 pixels
|
Detector size | 35 cm x 43 cm (approx 14" x 17")
|
Pixel size | 139 μm
|
Active Area | 34.1 cm x 42.4 cm (approx 13.4" x 16.7")
|
Active pixel area | 2456 x 3052 pixels
|
Detector pixels | 7.6 Megapixels
|
A/D conversion (bits) | 16 bits
|
Weight (incl. battery) | 3.6 kg approx. (7.93 lbs)
|
Ceiling height at source image distance | 270 cm
|
Column | 110 cm (44”)
|
Travel range Y axis(Lateral) | 1.8m (5' 11")
|
Travel range X axis(Longitudinal) | 3.05/4.05m (10'/13'3.4")
|
Travel range Z axis(Vertical) | 1.5m (4' 11")
|
RAM storage capacity | 4 Gb
|
Hard disk | 500 Gb total; 203 Gb for the image data (equivalent to approximately 11548 images)
|
