Waveform | |
Shock Delivery | |
Shock Series | |
Charge time | -
• Less than 5 seconds to the recommended adult energy level (150 Joules) with a new, fully-charged battery installed -
• Less than 6 seconds to the selected energy level (up to 200 Joules) with a new, fully charged battery installed -
• Less than 15 seconds to the selected energy level while connected to AC power only -
• The device powers on in manual defibrillation mode ready to deliver shock in less than: -
• 15 seconds with a new, fully-charged battery -
• The device powers on in AED mode ready to deliver shock in less than: -
• 24 seconds with a new, fully-charged battery even after 15 discharges of maximum energy |
Sensing for Pads/Paddles | |
Charge times | -
• Less than 5 seconds to the recommended adult energy level (150 Joules) with a new, fully-charged battery installed• Less than 6 seconds to the selected energy level (up to 200 Joules) with a new, fully charged battery installed• Less than 15 seconds to the selected energy level while connected to AC power only• The device powers on in manual defibrillation mode ready to deliver shock in less than:• 15 seconds with a new, fully-charged battery• The device powers on in AED mode ready to deliver shock in less than:• 24 seconds with a new, fully-charged battery even after 15 discharges of maximum energy |
Patient Impedance Range | |
